To make optional device available for use
195
Chapter 8
1
2
3
4
5
6
7
8
9
10
11
[c] Insert jump after feeding material
Setting whether or not to insert a non-data jump code automatically after feeding out beads
YES: To insert
When you desire to tighten stitching tension of beads, select "YES". However, productivity
will be decreased.
NO: Not to insert
[d] Moving up of device at frame stepping
YES: To perform
NO: Not to perform
1-4-2. How to operate
The following is an example that the device is equipped to the left side and Jump is set to "To insert" before
feeding out beads.
(1) To open screen
(2) To equip to left side
(3) To insert non-data jump code automatically
Proceed to "To make the air compressor available for use (Air Pressure Sensor)" continuously.
(āp.206)
Selecting "NO" will increase manufacturing efficiency. However, the device
could interfere with the frame resulting in its breakage depending on design or
frame type to use.
)ī
10 Lochrose embroidery device
