Name of each part
12
Chapter 2
WM03
1. Name of each part
1
8. Emergency stop switch (18-needle machine only)
(p.16)
9. Power cord
10. Color change system
11. Operation panel (p.13)
12. Power switch (p.30)
1. Thread course
2. Tension base
3. Snap-fit middle thread guide (p.246)
4. Needle Base LED Light (p.18)
5. Frame holder
6. Cylinder bed
7. Emergency stop switch (except 18-needle
machine) (p.16)
Only main sections are shown here. For details, refer to the separate parts list.
