Takeuchi TB016 User Manual

190
OPTIONS
Operating Ranges TB016 Canopy (Fully Extended Arm)
Telescopic Arm
4070(160.2) Max. digging height
2620(103.1) Max. digging depth
2215(87.2) Max. vertical digging depth
2580(101.6)
4230(166.5) Max. digging radius
4140(163.0) Max. ground digging radius
3035(119.5) Max. dumping height
2910(114.6)
Values are indicated in units of mm, inches in( ).
Bucket offset
520(20.5)
445(17.5)
R1220(48.0)
R1530(60.2)
R1440(56.7)
50(2.0)
575(22.6)
1525(60.0)
Front slewing radius
75
50
