SPECIFICATIONS
Unit: mm (inch)
Item Rubber crawlers
A Overall length 3445 (135.6)
B Upperstructur
e overall width 980 (38.5)
C Overall height 2345 (92.2)
D Slew radius 720 (28.3)
E Clearance height under upperstructur
e 460 (18.1)
F Crawler base 1155 (45.6)
G Crawler overall length 1520 (59.9)
H Crawler overall width (narr
ow) 980 (38.6)
H
2
Crawler overall width (wide) 1300 (51.2)
J Crawler shoe width 230 (9.1)
K Gr
ound clearance of undercarriage 205 (8.0)
L Minimum radius of equipment and attachment 1450 (57.0)
M Minimum radius of equipment at maximum fr
ont offset 1185 (46.7)
P Of
fset distance of bucket (Left) 395 (15.6)
Q Of
fset distance of bucket (Right) 555 (21.9)
R Dozer blade width (narr
ow) 980 (38.6)
R
2
Dozer blade width (wide) 1300 (51.2)
S Dozer blade height 250 (9.8)
T Fr
ont distance to axis of rotation 2725 (107.3)
U Dozer blade distance to axis of r
otation 855 (33.6)
V Boom swing angle (Left) 70°
W Boom swing angle (Right) 50°
X Overall length (dozer blade at r
ear) 3585 (141.1)
MACHINE DIMENSIONS
