8-4
OPTIONS
ATTACHMENT COMBINATION TABLE
The table below shows which bucket should be installed when the machine is using a
standard arm or long arm. Select a proper bucket by following the table.
• Consult with Takeuchi before installing an optional attachment.
• Do not use any attachments not approved by Takeuchi. Doing so may cause safety
problems. Or, it may adversely affect the machine’s operation or service life.
• We will not be held responsible for any injuries, accidents or damage to its products
caused by the use by a non-approved attachment.
• The swing stopper must be mounted when a bucket wider than a 450W bucket is
mounted. Failure to mount the swing stopper may result in the bucket hitting the
machine body.
√ :Can be used.
∆ :Can be used only for light operations (digging and loading of dry and loose soil or mud)
— :Cannot be used.
ATTACHMENT COMBINATION TABLE
Bucket
Rated capacity
m
3
(cu. yd.)
Bucket cutting width
mm (inch)
Standard arm
930mm (37 in.)
260W 0.020 (0.026) 265 (10.4) √
350W 0.027 (0.035) 335 (13.2) √
450W (Standar
d) 0.038 (0.049) 435 (17.1) √
500W 0.043 (0.056) 485 (19.1) √
3-hole bucket 0.049 (0.064) 457 (18.0) —
T
otal bucket weight = Within 116 (255 lb.) Within 485 (19.1) √
Hydraulic Br
eaker (TKB-72) √
