2-83
CONTROLS
Overload warning device
If the overload is not removed after the
overload warning hor
n is sounded, the
machine may tip over
. If the horn starts
sounding, stop operating the machine
and lighten the load.
If a weight greater than the lifting capacity is
applied or lifted, the overload warning device
is activated and the horn sounds. (When the
lift overload warning switch is tur
ned on.)
Lift overload warning switch
OFF
....
O
ff
ON
.....
On
ACCESSORIES
132
134
