2-18
CONTROLS
MULTI-INFORMATION DISPLAY
INDICATORS
10. Deceleration indicator lamp
........ Automatic deceleration
indicator
........ Deceleration indicator
Automatic deceleration indicator
It flashes when the automatic
deceleration switch is pressed and
remains lit while in the deceleration
mode.
Refer to “Deceleration button” on page
2-49.
Refer to “Automatic deceleration switch”
on page 2-55.
Deceleration indicator lamp
This lamp turns on when the deceleration
button is pressed. The lamp lights up to
indicate that the engine is in the
deceleration mode at low idling speed
(1150 rpm).
11. Exhaust temperature warning
indicator
<Applicable machine models 126100003
or later>
This indicator lights up to warn if the
exhaust temperature is abnormally
increased. Check for any flammable
items around the exhaust piping.
12. Glow indicator lamp
This indicator lamp turns off when the
engine preheating is completed.
13. DPF auto regeneration/inhibit
indicator lamp
<Applicable machine models 126100003
or later>
........ DPF auto regeneration
under way
........ DPF auto regeneration
inhibit
DPF auto regeneration under way
The DPF regeneration is automatically
performed by the engine, when certain
criteria are met. The operator only has to
check the display.
DPF auto regeneration inhibit
The DPF manual regeneration inhibit
symbol appears on the display when the
DPF manual regeneration under way or
the DPF auto regeneration under way is
cancelled.
Refer to “DPF manual regeneration/
inhibit select switch” on page 2-52.
14. DPF manual regeneration under way/
regeneration promoting indicator
<Applicable machine models 126100003
or later>
The indicator starts flashing and an alarm
starts sounding, if the accumulated PM
exceeds the limited amount on the DPF.
Immediately perform the manual DPF
regeneration.
Refer to “DPF manual regeneration/
inhibit select switch” on page 2-52.
15. Highland mode indicator lamp
Highland mode is selected.
Refer to “Power/Highland mode switch”
on page 2-55.
To Next Page
