Takeuchi TB260 User Manual

2-19
CONTROLS
MULTI-INFORMATION DISPLAY
........ High-speed travel
........ Low-speed travel
This lamp turns on when the travel speed
button is set to the 2nd (high) speed.
17. Power mode indicator lamp
This lamp lights up when the power
mode side of the Power/Highland mode
select switch is pressed. The maximum
engine output is maintained for as long
as this lamp is lit.
18. Lift overload warning indicator lamp
This lamp turns on when the lift overload
warning switch is turned on.
19. Auxiliary 2nd/4th select indicator lamp
........ Auxiliary 2nd is selected.
........ Auxiliary 4th is selected.
20. Auxiliary 1st one-way (one-way
circuit) indicator lamp
........ Auxiliary 1st auto tank is
selected.
........ Auxiliary 1st one-way is
selected.
No display: ....Two-way (two-way circuit) is
selected.
21. High-flow indicator lamp
This lamp flashes and then stays lit when
the auxiliary 1st flow rate is set to high-flow.
It also flashes when the high-flow setting
is changed.
22. Dozer blade float indicator lamp
(If equipped)
16.
Travel speed indicator lamp
........ This lamp lights up when
the float switch on the
blade lever is pressed.
23. Water temperature gauge
Indicates the temperature of the engine
coolant water. The indicator level must
be within the green range during
machine operation. The red range
indicates overheating.
24. Fuel gauge
Indicates the amount of fuel in the tank.
Be sure to fill up the tank before running
out of fuel.
25. Throttle opening position indicator
