Takeuchi TB260 User Manual

2-20
CONTROLS
MULTI-INFORMATION DISPLAY
The red range increases as the engine
load increases, indicating higher fuel
consumption. When the button (C) (Bar
meter key) is pressed in a normal screen,
the display is changed from the throttle
opening position to the lift load factor
and the PM accumulation amount (only
for machine models of 126100003 or
later), in this order.
• The lift load factor is displayed if there
is no change in the throttle opening
position for five seconds after the lift
alarm switch is turned on.
• The throttle opening position is
displayed if the highland mode switch
is turned on or there is a change in the
throttle opening position.
26. Auxiliary 1st flow rate indicator lamp
This lamp lights up to indicate which flow
rate setting is selected in the auxiliary 1st.
........ a Flow rate setting 1
........ b Flow rate setting 2
........ c Flow rate setting 3
........ d Flow rate setting 4
........ e Flow rate setting 5
........ f Flow rate setting 6
........ 1 Flow rate setting 7
........ 2 Flow rate setting 8
........ 3 Flow rate setting 9
Refer to “Auxiliary 1st flow rate setting”
on page 2-23.
27. Air conditioner indicator lamp
Lights up while the air conditioner is
operating.
28. Working light indicator
Lights up when the working light is
turned on.
29. Date and time indicator
Displays the date and
time set.
Refer to “Date and
time setting” on page
2-25.
30. Hour meter/Trip meter
• Hour meter
Displays the total
engine running time in
hours.
The rightmost digit
indicates tenths of
hours (6 minutes).
Set the inspection and maintenance
intervals according to the time displayed on
the hour meter.
• Trip meter
Three patterns of desired operating hours
can be displayed.
Refer to “Trip meter setting” on page 2-23.
