6-17
TROUBLESHOOTING
ENGINE ERROR CODE LIST
Error code
Error details DTC
SPN FMI
653
5 Injector 2 open circuit (Inherent location of the injector) P0202
6 Injector 2 coil short circuit P0265
3 Injector 2 short circuit P1265
654
5 Injector 3 open circuit (Inherent location of the injector) P0201
6 Injector 3 coil short circuit P0262
3 Injector 3 short circuit P1262
652
5 Injector 4 open circuit (Inherent location of the injector) P0203
6 Injector 4 coil short circuit P0268
3 Injector 4 short circuit P1268
4257 12 Injector drive IC error P0611
2797 6
Injector drive circuit (Bank 1) short circuit
(4TN: Common circuit for No.1, No.4 and all 3TN cylinders)
P1146
2798 6
Injector drive circuit (Bank 2) short circuit
(4TN: Circuit for No.2 and No.3 cylinders)
P1149
523462 13 IQA corrected injection amount for injector 1 error P1648
523463 13 IQA corrected injection amount for injector 2 error P1649
523464 13 IQA corrected injection amount for injector 3 error P1650
523465 13 IQA corrected injection amount for injector 4 error P1651
522571
3 High-pressure pump drive circuit (Low side VB short-circuit) P1641
6
High-pressure pump drive circuit (Low side GND short-
circuit)
P1643
633
3 High-pressure pump drive circuit (High side VB short-circuit) P0629
6
High-pressure pump drive circuit (High side GND short-
circuit)
P1642
5 High-pressure pump drive circuit (Open circuit) P0627
522572
6 High-pressure pump drive circuit (Drive current (high level)) P062A
11 High-pressure pump drive circuit (Pump overload error) P1645
