Takeuchi TB260 User Manual

7-5
SPECIFICATIONS
<Applicable machine models 126000002 or later /126100003 or later>
MACHINE DIMENSIONS
Unit: mm (inch)
Item
Middle arm Long arm
Rubber
crawlers
Steel
crawlers
Rubber
crawlers
Steel
crawlers
A Overall length 5540 (218.0)
5550 (218.5)
B Upperstructure overall width 1870 (73.6)
C Overall height
2560 (100.8)
2575 (101.4)**
2550 (100.4)
2565 (101.0)**
2560 (100.8)
2575 (101.4) **
2550 (100.4)
2565 (101.0) **
D Slew radius 1300 (51.2)
E
Clearance height under
upperstructure
635 (25.0) 625 (24.6) 635 (25.0) 625 (24.6)
F Crawler base 2050 (80.7) 2035 (80.2) 2050 (80.7) 2035 (80.2)
G Crawler overall length 2575 (101.3) 2560 (100.8) 2575 (101.3) 2560 (100.8)
H Crawler overall width 2000 (78.7)
J Crawler shoe width 400 (15.7)
K
Ground clearance of
undercarriage
330 (13.1) 325 (12.7) 330 (13.1) 325 (12.7)
L
Minimum radius of
equipment and attachment
2390 (94.0) 2420 (95.4)
M
Minimum radius of
equipment at maximum
front offset
1945 (76.6) 1975 (77.8)
P
Offset distance of bucket
(right swing)
655 (25.8)
Q
Offset distance of bucket
(left swing)
785 (31.0)
R Dozer blade width 2000 (78.7)
S Dozer blade height 430 (16.9)
T
Front distance to axis of
rotation
4240 (166.9) 4255 (167.5)
U
Dozer blade distance to axis
of rotation
1870 (73.6)
1930 (76.0)*
V Boom swing angle (Left) 78°
W Boom swing angle (Right) 55°
X
Overall length (dozer blade
at rear)
6110 (240.5)
6170 (242.9)*
6125 (241.2)
6185 (243.5)*
* : With an angle dozer blade
** : Canopy
