Takeuchi TB260 User Manual

7-7
SPECIFICATIONS
<Applicable machine models 126000002 or later /126100003 or later>
OPERATING RANGES
*: With an angle dozer blade
Unit: mm (inch)
Item
Middle arm Long arm
Rubber
crawlers
Steel
crawlers
Rubber
crawlers
Steel
crawlers
A Maximum reach 6120 (240.9)
6270 (246.9)
B
Maximum reach at ground
reference plane
5975 (235.3) 6130 (241.4)
C Maximum digging depth 3735 (147.1) 3745 (147.4) 3895 (153.4) 3905 (153.7)
D
Maximum vertical digging
depth
2830 (111.3) 2835 (111.7) 2980 (117.4) 2990 (117.7)
E
Reach at maximum vertical
digging depth
4175 (164.3)
4220 (166.1)
F
Maximum height of cutting
edge
5835 (229.7) 5825 (229.4) 5940 (233.9) 5930 (233.5)
G Maximum dumping height 4115 (162.0) 4105 (161.6) 4220 (166.1) 4210 (165.8)
H Minimum dumping height 1465 (57.6) 1455 (57.3) 1305 (51.5) 1300 (51.1)
J Dozer blade maximum lifting
430 (16.9)
445 (17.5)*
420 (16.5)
435 (17.2)*
430 (16.9)
445 (17.5)*
420 (16.5)
435 (17.2)*
K
Dozer blade maximum
lowering
430 (16.9)
450 (17.7)*
440 (17.2)
455 (18.0)*
430 (16.9)
450 (17.7)*
440 (17.2)
455 (18.0)*
