Takeuchi TB260 User Manual

2-31
CONTROLS
INSTRUMENT CLUSTER
........ Auxiliary 2nd is selected.
........ Auxiliary 4th is selected.
B. —
C. Auxiliary 1st One-way (one-way circuit)
........ Auxiliary 1st auto tank is
selected.
........ Auxiliary 1st one-way is
selected.
No display: ..... Two-way (two-way circuit)
is selected.
D. Lift overload warning/power mode
........ This lamp lights up when
the power mode side of
the Power/Highland mode
select switch is pressed.
The maximum engine
output is maintained for as
long as this lamp is lit.
E. DPF Auto Regeneration/Inhibit
........ DPF auto regeneration
under way
........ DPF auto regeneration
inhibit
DPF auto regeneration under way
The DPF regeneration is automatically
performed by the engine, when certain
criteria are met. The operator only has to
check the display.
DPF auto regeneration inhibit
The DPF manual regeneration inhibit
symbol appears on the display when the
DPF manual regeneration under way or
the DPF auto regeneration under way is
cancelled.
Refer to “DPF manual regeneration/inhibit
select switch” on page 2-52.
F. Highland Mode (If equipped)
This mode is used to reduce
the engine load due to the
hydraulic pump. When the
machine is operated at a high-
altitude site, the engine output
is decreased due to thin air. In such cases,
the hydraulic horse power is automatically
adjusted to prevent the engine from
stalling.
Refer to “Power/Highland mode switch”
on page 2-55.
Display the symbol when
the lift overload warning
switch is turned on.
A. Auxiliary 2nd/4th selection
Refer to “Power/Highland mode switch”
on page 2-55.
Refer to “Lift overload warning switch (If
equipped)” on page 2-57.
