Takeuchi TL12 User Manual

7-3
SPECIFICATIONS
<TL10>
Type Canopy Cab
MASS
Operating mass kg (lb) Rubber tracks 4680 (10320) 4770 (10515)
PERFORMANCE
Bucket capacity
(Standard bucket)
m
3
(cu. ft.) Heaped 0.458 (16.17)
Travel speed km/h (mph) Rubber tracks
1st 7.4 (4.6)
2nd 11.6 (7.21)
Gradeability (degrees) 30
Ground pressure kPa (psi) Rubber tracks 30.1 (4.36) 30.7 (4.45)
Noise level dB (A)
Sound power level
(ISO 6395:2008)
L
WA 104
Emission sound pressure level at the
operator’s position (ISO 6396, 2008:)
LpA 87
ENGINE
Manufacturer and model KUBOTA V3800-CR-TE4B
Rated output
Gross
(SAE J1995)
kW/min
-1
(hp/rpm) 68.6/2400 (92.0/2400)
Net
(ISO 14396)
kW/min
-1
(hp/rpm) 67.6/2400 (90.6/2400)
Net
(ISO 9249/
SAEJ 1349)
kW/min
-1
(hp/rpm) 64.4/2400 (86.4/2400)
Displacement ml (cu.in.) 3769 (230)
Starter V-kW 12-3.0
Alternator V-kW 12-0.96
Battery (IEC 60095-1) V-A·h 12-90
BASIC SPECIFICATIONS

Takeuchi TL12 Specifications

General

Brand	Takeuchi
Model	TL12
Category	Compact Loader
Language	English
