Takeuchi TL12 User Manual

7-4
SPECIFICATIONS
BASIC SPECIFICATIONS
<TL12>
Type Canopy Cab
MASS
Operating mass kg (lb) Rubber tracks 5270 (11620) 5375 (11850)
PERFORMANCE
Bucket capacity
(Standard bucket)
m
3
(cu. ft.) Heaped 0.579 (20.45)
Travel speed km/h (mph) Rubber tracks
1st 7.9 (4.91)
2nd 11.9 (7.39)
Gradeability (degrees) 30
Ground pressure kPa (psi) Rubber tracks 32.0 (4.64) 32.7 (4.74)
Noise level dB (A)
Sound power level
(ISO 6395:2008)
L
WA 105
Emission sound pressure level at the
operator’s position (ISO 6396, 2008:)
LpA 82
ENGINE
Manufacturer and model KUBOTA V3800-CR-TIE4B
Rated output
Gross
(SAE J1995)
kW/min
-1
(hp/rpm) 82.0/2400 (109.9/2400)
Net
(ISO 14396)
kW/min
-1
(hp/rpm) 80.8/2400 (108.3/2400)
Net
(ISO 9249/
SAEJ 1349)
kW/min
-1
(hp/rpm) 77.2/2400 (103.5/2400)
Displacement ml (cu.in.) 3769 (230)
Starter V-kW 12-3.0
Alternator V-kW 12-0.96
Battery (IEC 60095-1) V-A·h 12-90

Takeuchi TL12 Specifications

General

Brand	Takeuchi
Model	TL12
Category	Compact Loader
Language	English
