II – 4
SPECIFICA
TIONS
SPECIFICA
TION DIAGRAMS
Machine Dimensions
Unit: mm
Standard Bucket
Rubber Crawler
A
B
C
D
E
F
G
H
J
K
L
M
3430
2740
1390
2235 (2120
∗
)
310
1580
320
1430
985 (980
∗
)
1675
510
30
°
Unit: mm
Standard Bucket
Rubber Crawler
A
B
C
D
E
F
G
H
3905
3030
2370
730
2080
1375
1585
30
°
Operating Range
SPECIFICATION DIAGRAMS
T7K001
1A
L
M
D
J
H
K
C
F
G
A
E
B
T7K0021A
F
H
C
A
D
B
G
E
REV. 1
Canopy
Cab
←
←
←
2235
←
←
←
←
985
←
←
←
∗
: 21300004~21301098
Canopy
Cab
←
←
←
←
←
←
←
←
22
24
Table of Contents
List of Revisions
2
Machine Serial Number
4
Manual Control
4
Machine Front and Rear, Left and Right
4
Foot of the Page
5
Contents
6
General
7
Table of Contents
8
Safety Precautions
9
Signal Words
9
Anti-Explosive Lighting
10
Use the Correct Tools
10
Replace Important Safety Parts Periodically
10
Always Clean the Machine
11
Stop the Engine before Performing Maintenance
11
Stay Clear of Moving Parts
11
Securely Block the Working Equipment
11
Cautions on Working on the Machine
12
Use Caution When Fueling
12
Handling of Hoses
12
Disconnect the Battery
13
Handling of the Accumulator
13
Avoid Battery Hazards
14
Safety Signs
14
Checks after Maintenance
14
Disposing of Wastes
14
Cautions During Disassembly and Assembly
15
Cautions During Removal and Installation of the Hydraulic Units
15
Cautions During Removal and Installation of Piping
16
Handling of Seals
16
Bite Type Pipe Fitting for Steel Pipe
17
Hydraulic Hoses
17
Tightening Torques
17
Joints for Piping
18
Joints for Piping (O-Ring Seal Type)
18
Bolts and Nuts (for ISO Strength Category 10.9)
19
Specifications
20
Names of Components
22
Specification Diagrams
23
Machine Dimensions
23
Operating Range
23
Specification Tables
24
