1. Page number
The following page numbers are assigned to each respective page. And if there are additional pages, the addition
codes are supplied. Please file the sheets in the order of the page numbers.
Page No.
X–XX
Page number within chapter
Chapter Number
Page Addition
X–XX–X
Addition Code
Example: II-8
II-9
II-9-1............... A page is added between page 9 and page 10.
II-10
2. Revision number
Indicates the number of revisions made to this manual. This number is printed on the page that reflects this
revision.
If a page has been revised, it is to be used in place of the page used before revision and it is not necessary to keep
the old page.
3. Model(s)
SYMBOLS
means “Please refer to the section quoted.”
Indicates the tightening torque at the specific section that requires special attention in designing.
Indicates the mass of a part or device.
FOOT OF THE PAGE
6. Bleed the air from the cylinders.
a. With the engine running at slow, extend and contract the
cylinders 4 or 5 times.
• Move the piston rods to 100 mm before the stroke end.
DO NOT extend them completely.
b. Repeat step “a” above with the engine running at full,
then run it at slow and extend the piston rods completely
to the stroke end.
L4A100E
REV. 1
