Tally Dascom DL-820 User Guide V1.0
48
GateWay – User defined. If Static Address Method is selected, type in the gateway address of the
network.
WiFi Port – Default value = 9100
Specification:
Item
Parameters
Wireless
Wireless Standard
IEEE802.11b/g/n
Frequency Range
2.412~2.484 GHz
Receiver Sensitivity
802.11b: -82 dBm @ 11Mbps （typical）
802.11g: -68 dBm @ 54Mbps（typical）
Data Rate
802.11b: 1,2,5.5,11 Mbps
802.11g: 6,9,12,18,24,36,48,54 Mbps
Modulation
DSSS, OFDM, DBPSK, DQPSK, CCK, QAM16/64
Transmit Power
802.11b: 16±2 dBm（typical）
802.11g: 13±2 dBm（typical）
Antenna Interface
IPX/microstrip antenna
