TANDBERG Videoconferencing System - Controlling the Main Camera; Selecting video sources; Presets

TANDBERG Videoconferencing SystemGeneral use
8
Presets
The preset buttons enable you to pre-store up to ten different camera positions.
Selecting presets
To select a preset, use the keys P1 P2 P3 or press P until the on-screen indicator ‘Preset 0-9’appears and use
0-9 to activate P0-P9 presets. To exit ‘Preset’ mode, press OK.
P1-P3 are the same presets as when pressing P and then a number key 1-3.
Storing presets
To store the current camera position, audio and video source:
• Press STORE once and wait for the on-screen indicator to appear.
• Then press one of the keys P1 P2 P3 or a number key 0-9.
store
P 1
P 2
P 3
Selecting video sources
Press: to select a video source.
doc cam main cam
vcr pc
aux
OK
zoom
Controlling the Main Camera
Moving / zooming camera
To control the Main Camera use the keys below:
for pan/tilt and for zooming.
