Chapter 19 – Technical Specifications
19.1 Overview
This appendix provides tables of technical specifications, options, settings, and electromagnetic compliance information for
the t:slim System.
19.2 t:slim Pump Specifications
The following table lists the t:slim Pump specifications and their related details.
Specification Type Specification Details
Classification
External PSU: Class II, Infusion Pump. Internally-powered equipment, Type BF applied part. The risk of ignition
of flammable anesthetics and explosive gases by the pump is remote. While this risk is remote, it is not
recommended to operate the t:slim Pump in the presence of flammable anesthetics or explosive gases.
Size
3.13˝ x 2.0˝ x 0.6˝ (L x W x H) – (7.95 cm x 5.08 cm x 1.52 cm)
Weight (with full disposable)
3.95 ounces (112 grams)
Operating Temperature Range
41°F and 98.6°F, 5°C and 37°C at maximum relative humidity of 90% non-condensing
Storage Temperature Range
-4°F and 140°F -20°C to 60°C at maximum relative humidity of 90% non-condensing
Atmospheric Pressure
700 hPa to 1060 hPa (equivalent from 10,000 ft. to Dead Sea elevation)
Reservoir Volume
3.0 mL or 300 units
Cannula Fill Amount
0.1 to 1.0 units of insulin
Insulin Concentration
U-100
Alarm Type
Visual, audible, and vibratory
table continued on next page …
