Tangent AMP-100 User Manual

TECHNICAL DATA
Technical data
Phono input
Line level inputs
Input impedance 47 KOhm
Input sensitivity 3.8mV
(Tuner, CD, DVD, AUX1, AUX2)
Input impedance 47 Kohm
Input sensitivity 200mV
Output impedance Line out 100KOhm
Headphones 300Ohm
Maximum output level Line out 740mV
Headphones 1.25V
Treble +/- 14dB
Bass +/- 14dB
Output power 2 x 50 Watt at 4 Ohm
2x40Wattat8Ohm
Frequency response 10Hz to 63KHz (-3dB)
Distortion <0.05%
Signal/noise ratio >90dB
Voltage and power consumption See the rear panel
Dimensions (WxDxH) 430 x 290 x 75mm
Line level outputs
Tone control
We reserve the right to change the technical data and the design of the product without notice as a result of further development.
19

Tangent AMP-100 Specifications

General

Brand	Tangent
Model	AMP-100
Category	Amplifier
Language	English
