FRONT PANEL AND CONNECTIONS
Connections
1. Stereo Output:
2. AC input:
Analogue stereo output. For connection to stereo amplifier or receiver with analogue
input.
For connection of mains voltage. Make sure that the plug has been correctly inserted, and that
the voltage corresponds to the text printed on the back panel of the cabinet.
Item No.:
Power Rating 230-240 V AC~50Hz
Model: CDP-100
Max Power Consumption: 30W
Serial No.:
~AC INPUT
230-240V 50Hz
STEREO OUTPUT
Explanation of LCD display
This unit does not feature any OSD (On Screen Display). Instead it features a more descriptive LCD display that displays all the
information required. Below you can see a picture of the display and an explanation of the various symbols.
12
1 2
CD 20-008-04:26
Track number
Track time
Blinks when random is activated
Total numbers of tracks
Disc type.
Shows what kind
of disc is loaded.
(CD or Mp3)
Blinks when repeat all is activated
Blinks when repeat one is activated
