TURNSTILE MECHANISM INFORMATION
4.2 How to open the cover
Figure 4.2
Figure 4.3
To access the interior parts of the turnstile, turn the top cover lock by turning it
counterclockwise using the key provided with your turnstile as shown in the figures above. (Figure
4.2 and Figure 4.3)
Figure 4.4
Figure 4.5
After unlocking, push the top cover of the turnstile back by gently lifting and remove it.
(Figure 4.4 and Figure 4.5)
| 19 |
It does not matter whether the turntable has an angle cover or a flat cover. Both are
opened as described above.
