9
Fitting the inlet/outlet hoses
CONNECTING THE HOSE TO THE INLET VALVE
Connect the hose to the inlet valve on the pipework. Insert the other
end of the hose with the adaptor elbow into the inlet valve on the water
softener. Push the adaptor elbow into the valve inlet as far as it will go.
Secure with adaptor clip as below.
CONNECTING THE HOSE TO THE OUTLET VALVE
Connect the hose to the outlet valve on the pipework. Remove the plastic
plug from the outlet connection on the water softener, if present. Insert the
other end of the hose with the adaptor elbow into the outlet valve on the
water softener. Push the adaptor elbow into the valve outlet as far as it
will go. Secure with adaptor clip as below.
SECURE THE ADAPTOR ELBOW
Snap the two large adaptor clips into place,from the top down Be sure
they snap firmly into place so that the adaptors will not pull out. Pull on
the adaptors to ensure a tight fit has been achieved.
