52
General
Power requirements AC 220~240V, 50/60 Hz
Power consumption 99.3 mA
Dimensions (approx.) 430 X 81 X 360 mm (w x h x d)
Mass (approx.) 5.8 kg (17.6 lbs)
Operating temperature 5˚C to 40˚C (41˚F to 104˚F)
Timer 24-hour display type
RF Modulator UHF 22-68 (adjustable)
Operating humidity 5 % to 90 %
DVD Section
Laser Semiconductor laser, wavelength 650 nm
Signal system PAL/NTSC
Frequency response DVD (PCM 96 kHz): 8 Hz to 44 kHz
DVD (PCM 48 kHz): 8 Hz to 20 kHz
CD: 8 Hz to 20 kHz
Signal-to-noise ratio More than 65 dB (analog out connectors only)
Harmonic distortion Less than 1.0%
Dynamic range More than 60 dB (DVD, CD)
Outputs
S-VIDEO OUT (Y) 1.0 V (p-p), 75 ohms, negative sync, Mini DIN 4-pin x 1
(C) 0.3 V (p-p) 75 ohms
VCR Section
Head system 6 heads helical scan azimuth system
Television system PAL/SECAM colour system
Recording format PAL/MESECAM
RF OUT G
Tape speed PAL/MESECAM; 23.39 mm/s (SP), 16.69 mm/s (LP)
NTSC (Playback only); 35.35 mm/s (SP), 16.67 mm/s (LP),
11.12 mm/s (EP)
Maximum recording time SP: 4 h (E-240 tape), LP: 8 h (E-240 tape)
Rewind time About 180 min (E-180 tape)
Input level VIDEO: 1.0 V(p-p), 75 ohms, unbalanced
AUDIO: -6.0 dBm, more than 10 kohms (SCART)
-6.0 dBm, more than 47 kohms (RCA)
Output level VIDEO: 1.0 V(p-p), 75 ohms, unbalanced
Signal-to-noise ratio VIDEO: More than 43 dB
AUDIO: More than 72 dB (Hi-Fi)
More than 42 dB (Mono)
Dynamic range AUDIO: More than 85 dB
Tuner Section
Tuning range FM: 87.5 - 108.0 MHz
AM: 522 - 1611 kHz
Intermediate frequency FM: 10.7 MHz
AM: 450 kHz
Amplifier Section
Stereo mode 60W + 60W (8 ohm at 1 kHz, THD 10%)
Surround mode Front: 60W + 60W (THD 10%)
Centre: 60W
Surround:60W + 60W (8 ohm at 1 kHz, THD 10%)
Subwoofer: 120W (4 ohm at 30 Hz, THD 10%)
