38
TASCAM CD-9010
11 – Specifications
Media and file formats
Supported media
CD, CD-R (CD-DA audio discs, ISO9660 Level1/Joliet/Romeo
data discs)
Playback file formats
WAV: 44.1/48kHz, 16/24-bit
CD-DA: 44.1kHz, 16-bit
Number of channels
2 (stereo)
1 (mono)
Inputs and outputs
Analog audio inputs and outputs
MIX INPUTS (BALANCED)
Connector: XLR-3-31 (1: GND, 2: HOT, 3: COLD)
Input impedance: 10 kΩ
Nominal input level: +4 dBu (1.23 Vrms)
Maximum input level: +24 dBu (12.28 Vrms)
LINE OUTPUTS (BALANCED)
Connector: XLR-3-32 (1: GND, 2: HOT, 3: COLD)
Output impedance: 200 Ω
Nominal output level: +4 dBu (1.23 Vrms)
Maximum output level: +24 dBu (12.28 Vrms)
MONITOR OUTPUTS (UNBALANCED)
Connector: RCA pin jack
Output impedance: 100 Ω
Nominal output level: –10 dBv (0.32 Vrms)
Maximum output level: +6 dBv (2 Vrms)
PHONES
Connector: 6.3mm (1/4") standard stereo jack
Maximum output level: 45 mW+45 mW
(THD+N 0.1%, 32 Ω)
Digital audio output
DIGITAL OUT (COAXIAL)
Connector: RCA pin jack
Format: IEC60958-3 (S/PDIF consumer standard)*
Output impedance: 75 Ω
*When the
DIGITAL OUT TYPE
in the
SYSTEM
menu is set to
CONSUMER
.
DIGITAL OUT (XLR)
Connector: XLR-3-31
Format: AES3-2003/IEC60958-4 (AES/EBU)**
Output impedance: 110 Ω
**When the
DIGITAL OUT TYPE
in the
SYSTEM
menu is set to
PRO
.
Control inputs and outputs
WORD IN
Connector: BNC
Input voltage: 5V TTL equivalent
Input impedance: 75 Ω
Permissible frequency variation during
external synchronization: ±100 ppm
Switchable clock terminator
WORD THRU
Connector: BNC
Output voltage: 5V TTL equivalent
Output impedance: 75 Ω
REMOTE IN (SERIAL)
Connector: D-sub 15-pin
REMOTE IN (PARALLEL)
Connector: D-sub 37-pin
Maximum input voltage: +5.5 V
High-level minimum input voltage: +3.75 V
Low-level maximum input voltage: +1.25 V
Output format: open drain (withstand voltage 50 V,
maximum 100 mA)
Low-level maximum output voltage: 0.5 V
+5V power maximum supplied current: 100 mA
Audio performance
Frequency response
20 Hz–20 kHz: ±0.5 dB
Distortion
0.005% or less
S/N ratio
100 dB or more
Dynamic range
95 dB or more
Channel separation
95 dB or more
NOTE
All audio performance ratings are for playback according to
JEITA CP-2150 standards
