Task Force ZE04 - Step 3; Step 4; Step 5

6
OPERATING INSTRUCTIONS
Step 3
Insert the wand (A or B) into spray gun, and twist 1/4 turn until rectangular tab appears.
A or B
Fig. 4
F
C
I
L-shape connector
Fig. 5
Step 4
Attach the L-shape coupler end of the extension hose (F) into the water outlet and the other end into the
hose reel (H). Fasten the extension hose (I) tightly onto the gun assembly (C) and tighten to avoid leakage.
Step 5
Attach garden hose to water supply and turn water on.
Fig. 6
