UltraForce
44
8.3 Parts list
No. Description Qty.
1 UPRIGHT FRAME 1
2 PULLEY WHEEL WITH LOGO PLATE 4
3 TAPPING SCREW q;2x4mm 12
4 PULLEY WHEEL 8
5 REARING 12
6 PLASTIC PULLEY COVER 12
7 OIL BEARING 24
8 BOTTOM PULLEY BRACKET 2
9 PERFORATED COVER 1
10A FRONT TOP COVER CAP 1
10B FRONT BOTTOM COVER CAP 1
11 REAR COVER CAP 2
12 ALUMINIUM LOGO PLATE 1
13 M4X10 PHILLIPS BOLT (TAPPING SCREW q;3.5x10mm ) 12
14 M60 ROUND TUBE CAP 6
15 PHILLIPS BOLT M6x29mm 4
16 BACKREST SUPPORT FRAME 1
17 CROSS BAR 1
18 BACKREST HANDLEBAR 1
19 FOAM GRIP q;31.4xq;25.4x450 1
20 ALLEN BOLT M8x40mm 2
21 1" SQUARE TUBE CAP 2
22 OVAL END CAP 2
23 RUBBER PADDER-PULLEY SHROUD 4
24 BOLT M10x47mm(THREAD LENGTH 12mm) 4
25 ACORN NUT M10 20
26 BASE FRAME 1
27 BASE PLATE 1
28 BASE PLATE PAD 3
29 ROLLER 2
30 PLASTIC ROLLER CAP(L) 1
31 PLASTIC ROLLER CAP(R) 1
32 ALLEN BOLT M8x46mm(THREAD LENGTH 10mm) 2
33 PHILLIPS SCREW M6x20mm 1
