Taurus Z9 - Parts List

Z9
29
8.3 Parts list
No. Description Specications Qty.
1 Main Frame 1
2 Front Stabilizer 1
3 Rear Stabilizer 1
4L Left Triangle Cap 95.7*57.2*51.3 2
4R Right Triangle Cap 95.7*57.2*51.3 2
5 Allen Bolt M8x1.25x20L,8.8level 12
6 Spring Washer D15.4xD8.2x2T 12
7 Flat Washer D16xD8.5x1.2T 12
8 Front Post 1
9 Seat Post 1
10 Seat 150*260*65,clamp,DD2681 1
11 Seat Adjustable Tube 1
12 L Knob 25L M12*25L 2
13 Handlebar 1
14 Computer Fixing Plate 1
15 D Plug 70*45*14 1
16 Cover Of Front Post 80*55*147 1
17 Protective Cover 80*55*61 1
18 Inner Insert 80*55*147 1
19 Stop Plate(1) 39*35*17 2
20 Sping D12.5*D1.2*20.7 2
21 Stop Plate(2) 38*35*17 2
22 L Knob 50L M10*50L 2
23L Left Chaincover 744.3*512.4*77.7,with electric hole 1
23R Right Chaincover 744.3*512.4*82 1
24L Left Crank 170*9/16"-20BC 1
24R Right Crank 170*9/16"-20BC 1
25L/R Pedal JD-304,9/16",double bearing-w/o SPD 1
26 Bolt M8x1.0x16,10.9 level 2
27 Bolt Cover D23x6.5 2
28 Screw M10*1.5*20L 5
