Model 142 Operator Parts Identification
140407
Section 4 Operator Parts Identification
ITEM DESCRIPTION PART NO.
1 COVER A.-HOPPER X49633
2 FLOAT A.- MIX LEVEL X39690
3 TUBE-FEED-.166HOLE-SS 035819
4 SHIELD - SPLASH-PLASTIC 039444
5 PAN A.- WHITE FRONT DRIP X43474
6 SEAL- U- CUP 080534
7 BEATER A. X24689
8 BEARING - FRONT 023262
9 O- RING- 2- 3/4 OD X .139W 019998
ITEM DESCRIPTION PART NO.
10 BEARING- GUIDE 014496
11 DOOR A. - PARTIAL-1 SPOUT X38959- SER
12 CAP-DESIGN 1.010”ID- 6 PT 014218
13 NUT-STUD 034829
14 ARM - VALVE LIFTER 024761
15 HANDLE-DRAW 024762
16 O - RING - 3/4 OD X .103W 015835
17 O - RING - 7/8 OD X .103W 014402
18 VALVE- DRAW 024763
