Taylor 336 User Manual

7
Models 336, 338 & 339 Operator Parts Identification
111101
Section 4 Operator Parts Identification
Model 336
Figure 1
Item Description Part No.
1 Cover A. --Hopper X37963 --SER
2 Pan--Drip 17 --1/4” Long 027504
3 Panel--Upper Side Left 028740
4 Orifice 022465--100
5 O --Ring 3/8 OD x .070 W 016137
6 Tube--Feed 5/32 Dia. Hole 043461--2
7 O --Ring .563 OD x .070 043758
8 Panel--Rear 029816
9 Louver--Side Top 051191
10 Panel--Upper Side Right 028741
Item Description Part No.
11 Panel A.--Lower Side (R & L) X24424
12 Adaptor A.--Caster X18915
13 Caster--Swivel 5/8 Stem 4” Wheel 018794
14 Caster--4” Swv 5/8 Stem w/Brake 034081
15 Panel--Service *336* 042824
16 Tray --Drip 16--7/8 L x 5--1/8 020157
17 Shield--Splash 022765
18 Stud--Nose 022822
19 Panel A.--Front X42821 --SP1
20 Gasket--Hopper Cover--8 Qt. 037042
