6
Introduction
Models 340/341/342
Model 342 Specifications
Freezing Cylinder
T wo, 7 quart (6.6 liter) capacity.
Mix Hopper
T wo, 20 quart (18.9 liter) capacity.
Beater Mo tor
T wo, .25 hp. motor.
Refrigeratio n Unit
T wo, approximately 7,500 btu/hr compressors.
Refrigerant 404A.
Electrical
Electrical
Two dedicated connections.
Maximum
Fuse Size
Minimum
Circ uit Ampacity
Electrical Left Right Left Right
115/60/1 Air 40 30 29 21
208--230/60/1 Air 20 20 16 13
208--230/60/1 Water 20 20 14 13
208--230/60/3 Air 15 15 13 9
220--240/50/1 Air 15 15 14 10
380--415/50/3N~Air 10 7 9 6
For exact electrical information, always refer to the
data label of the unit.
Air Cooled
Clearance: Minimum 3” (76 mm) around all sides. A
deflector is provided to prevent recirculation of warm
air.
Water Cooled
W ater inlet and drain connections under side of base
1/2” FPT.
Dimensions
Width: 26--7/16 (672 mm)
Depth: 33” (838 mm)
Height: 59--7/8 (1521 mm)
Floor Clearance: 7--1/2” (191 mm) mounted on
standard casters.
Approximate Weights
Net: 519 lbs. (235.4 kgs.)
Crated: 609 lbs. (276.2 kgs), 48.1 cu. ft. (1.3 cu. m.)
Specifications are subject to change without notice.
This unit is designed and constructed to meet stringent
safety and sanitation requirements for NSF, UL, and
CSA.
