Models 340/341/342
Parts
081009
Model 340 Parts Identification
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X39936-SP1
1a BEARING-REAR SHELL 032511
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 GEAR A.*REDUCER 4.92:1 015985
2a COUPLING-DRIVE 018962
3 WASHER-3/8 USS FLAT CR3 000653
4 SCREW-5/16-18X1 HEX HEAD 016178
5 PULLEY-AK69 X 5/8 051012
6 BELT-V-4L460 013859
7 PULLEY-AK23-1/2 013997
8 MOTOR-1/4 HP 014477-
9 SCREW-5/16-18X5/8 SERR. 017326
10 GUIDE A.-DRIP PAN X47190
11 SCREW-10X3/8 SLOTTED HEX 015582
12 CONDENSER-AC-15LX14H 046558
13 SCREW-1/4-20X5/8 SERR. 017522
14 NUT-1/4-20 WHIZ FLANGE 017523
15 SHROUD-FAN 052472
16 FAN-5 BLADE 12"PUSH 32° 047279
17 MOTOR-FAN 80 WATT 1550 051744-
18 BRACKET-FAN 038641
19 SCREW-10-32X3/8 SLTD RND 002742
20 LEG-4"·SS-W/ORING 013458
21 SCREW-10-32X3/8 UNSL HWH 039381
22 BOX A.-CAP&RELAY X52419-
23 NUT-5/16-18 WHIZ FLANGE 017327
24 SLEEVE-MOUNTING-COMP. 039924
25 GROMMET-COMPRESSOR MT 037428
ITEM DESCRIPTION PART NO.
26 WASHER-5/16 USS FLAT CR3 000651
27 SCREW-5/16-18X1-3/4 019691
28 COMPRESSOR
RS80C1E-CAV-224
051958-
29 SWITCH-PRESSURE 405 PSI 052663
30 VALVE-ACCESS-1/4 MFL X 3/8 053565
31 BRACKET-VALVE-ACCESS 055175
32 SCREW-8X1/4 SLTD HEX 009894
33 DRYER-FILTER-HP62-3/8 X 1/4 048901
34 VALVE-EXP-AUTO-1/4S X 1/4 046365
35 BOLT-CARRIAGE 1/4-20 X 3/4 012347
36 PANEL A.-FRONT X46881
37 SWITCH A.-TOGGLE X15204
38 SCREW-8X1-1/4 SLTD PAN A 028540
39 WASHER-#10 FLAT 18-8 SS 037841
40 TIMER-DELAY ON MAKE-10 029312-
41 LIGHT A.-ADD MIX-AMBER X47218-
42 SWITCH A.-TORQUE X29601
43 ARM A.-ANTICIPATOR X29556
44 SCREW-8X3/8 SAW SLOT PAN 013234
45 BRACKET-SOLENOID 030245
46 SOLENOID-PULL 030202-
47 STUD-NOSE
CONE-5/16-18X5/16
013496
48 BRACKET-CONTROL BOX 016197
49 COVER-RELAY BOX 015311
50 CONTROL A. X52469-
51 PROBEA.-MIX*SQUARE* X30922
52 DISC-PROBE *SQ HOLE* 030965
53 SPACER-PROBE *SQ HOLE* 030966
To Next Page
