29
Models 340/341/342
Parts
081009
Model 341 Parts Identification
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X39936-SP1
1a BEARING-REAR SHELL 032511
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 GEAR A.*REDUCER 4.92:1 015985
2a COUPLING-DRIVE 018962
3 WASHER-3/8 USS FLAT CR3 000653
4 SCREW-5/16-18X1 HEX HEAD 016178
5 PULLEY-AK69 X 5/8 051012
6 BELT-V-4L400 007590
7 SCREW-10X3/8 SLOTTED HEX 015582
8 SHROUD-TOP PANEL 013820
9 VALVE-ACCESS 1/4FL X 3/8 043232
10 SHROUD-LEFT 013821
11 SWITCH-PRESSURE 405 PSI 052663
12 CONDENSER-
AC-12LX18HX2.6T-3R
048233
13 SCREW-1/4-20X5/8 SERR. 017522
14 NUT-1/4-20 WHIZ FLANGE 017523
15 BLOWER A. X30153-
15a SCREEN-BLOWER 030158
16 SHROUD-RIGHT 013822
17 DRYER-FILTER-HP62-3/8 X
1/4S
048901
18 VALVE-EXP-AUTO-1/4S X 1/4 046365
19 COMPRESSOR
RS80C1E-CAV-224
051958-
20 SCREW-5/16-18X1-3/4 019691
21 WASHER-5/16 USS FLAT CR3 000651
22 GROMMET-COMPRESSOR MT 037428
23 SLEEVE-MOUNTING-COMP. 039924
ITEM DESCRIPTION PART NO.
24 NUT-5/16-18 WHIZ FLANGE 017327
25 BOX A.-CAP&RELAY X52636-
26 COVER-CAP & RELAY BOX 030315
27 ADAPTOR A.-CASTER X18915
28 CASTER-SWV 5/8 STEM 4IN
WHEEL
018794
29 SCREW-10-32X3/8 UNSL 039381
30 PANEL-SERVICE 013638-SP1
31 COVER-RELAY BOX 015311
32 CONTROL A.R* X49284-
33 PANEL A.-FRONT X46881
34 BOLT-CARRIAGE 1/4-20 X 3/4 012347
35 SCREW-5/16-18X5/8 SERR. 017326
36 MOTOR-1/4 HP 014477-
37 PULLEY-AK23-1/2 013997
38 GUIDE A.-DRIP PAN X47190
39 SWITCH A.-TORQUE X29601
40 ARM A.-ANTICIPATOR X29556
41 SCREW-8X3/8 SAW SLOT PAN 013234
42 TIMER-DELAY ON MAKE-10 029312-
43 WASHER-#10 FLAT 18-8 SS 037841
44 SCREW-8X1-1/4 SLTD PAN A 028540
45 LIGHT A.-ADD MIX-AMBER X47218-
46 SWITCH A.-TOGGLE X15204
47 SOLENOID-PULL 030202-
48 BRACKET-SOLENOID 030245
49 STUD-NOSE CONE-5/16-18 013496
50 PROBEA.-MIX*SQUARE* X30922
51 DISC-PROBE *SQ HOLE* 030965
52 SPACER-PROBE *SQ HOLE* 030966
