33
Models 340/341/342
Parts
081009
Model 342 Parts Identification
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X39936-SP1
1a BEARING-REAR SHELL 032511
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 GEAR A.*REDUCER 4.92:1 015985-SER
2a COUPLING-DRIVE 018962
3 WASHER-3/8 USS FLAT CR3 000653
4 SCREW-5/16-18X1 HEX HEAD 016178
5 PULLEY-AK69 X 5/8 051012
6 BELT-V-4L430 009613
7 SHROUD-COND 046576
8 SHROUD-COND 046575
9 CONDENSER-AC-12LX18H 048233
10 BLOWER A. (SEE PG. 45) X47833-
10a SCREEN-BLOWER 030158
11 SHROUD-COND 046574
12 VALVE-ACCESS 1/4FL X 3/8 043232
13 SWITCH-PRESSURE 405 PSI 052663
14 STUD-NOSE CONE-5/16-18 013496
15 MOTOR-1/4 HP 014477-
16 GUIDE A.-DRIP PAN X28698
17 PULLEY-AK23-1/2 013997
18 DRYER-FILTER-HP62-3/8X1/4 048901
19 VALVE-ACCESS-1/4 MFLX1/4 047016
20 SCREW-5/16-18X1-3/4 019691
21 WASHER-5/16 USS FLAT CR3 000651
22 GROMMET-COMPRESSOR MT 037428
ITEM DESCRIPTION PART NO.
23 SLEEVE-MOUNTING-COMP. 039924
24 NUT-5/16-18 WHIZ FLANGE 017327
26 VALVE-EXP-AUTO-1/4SX1/4 046365
25 COMPRESSOR
RS80C1E-CAV-224
051958-
27 CONTROL A. RIGHT
(SEE PG. 38)
X49284-
28 ADAPTOR A.-CASTER X18915
29 CASTER-SWV 5/8 STEM 4IN 018794
30 SCREW-10-32X3/8 UNSL HWH 039381
31 BOX A.-CAP&RELAY (SEE PG 43)
32 COVER-RELAY BOX 015311
33 PANEL-SERVICE 024439-SP1
34 CONTROL A. LEFT
(SEE PG. 39)
X4928427SP
35 BOLT-CARRIAGE 1/4-20 X 3/4 012347
36 PANEL A.-FRONT X25807
37 PLATE-DEC 022602-BLK
38 SWITCH-TOGGLE 014464
39 SWITCH A.-TORQUE
(SEE PG. 47)
X29601-SER
40 TIMER-DELAY ON MAKE-10 029312-
41 LIGHT-ADD MIX-AMBER 047141-
42 ARM A.-ANTICIPATOR MECH. X29556-SER
43 BRACKET-SOLENOID MTG 030245
44 SOLENOID-PULL 030202-
45 PROBEA.-MIX*SQUARE* X30922
46 DISC-PROBE *SQ HOLE* 030965
47 SPACER-PROBE *SQ HOLE* 030966
