Taylor 340 Service Manual

35
Models 340/341/342
Parts
081009
Model 342 Panel Identification
ITEM DESCRIPTION PART NO.
1 LOUVER-SIDE-TOP 051191
2 BUSHING-PANEL 013289
3 COVER A.-HOPPER X38458-SER
3a KNOB-MIX COVER 025429
4 TRIM-REAR CORNER-LEFT 013761
5 PANEL-REAR 017563
6 GASKET-HOPPER CVR-20 QT 038375
7 HOOD 023263
8 TRIM-REAR CORNER-RIGHT 013663
9 PANEL-UPPER SIDE-RIGHT 028701
10 PAN-DRIP 11-5/8 LONG 027503
11 PANEL A.-SIDE-LOWER RIGHT X44855-SER
ITEM DESCRIPTION PART NO.
12 SCREW-1/4-20X3/8 RHM-SS 011694
13 ANGLE-PANEL-RIGHT 013828
14 PANEL-SERVICE 024439-SP1
15 ANGLE-PANEL-LEFT 013829
16 PANEL A.-SIDE-LOWER LEFT X44853-SER
17 TRAY-DRIP 22-7/8L X 5-1/8W 014533
18 SHIELD-SPLASH 037041
19 PANEL A.-FRONT X25807
20 DECAL-DEC 021872
21 PLATE-DEC-TWIN 022602-BLK
22 PANEL-UPPER SIDE-LEFT 028700
