41
Models 340/341/342
Parts
Box A.--Cap & Relay X50292--12 -- Model 340 (115/60/1 Tecumseh)
ITEM DESCRIPTION PART NO.
1 SCREW --8--32X1/4 SLTD
ROUND
000953
2 WASHER--#8 EXTERNAL
TOOTH
000964
3 RELAY--START--COMPRESSOR 047609
4 CONNECTOR--BX 3/8 STR --2 014569
5 SLEEVE --WIRE 7/16 ID 020919--20
6 CONNECTOR--BX 3/8 90 DEG 001793
ITEM DESCRIPTION PART NO.
7 SCREW --10X3/8 SLOTTED HEX 015582
8 COVER--CAP.RELAY BOX 030315
9 LABEL--WIRING SINGLE PHASE 036880--1
10 CAPACITOR--RUN 15UF/370V 027087
11 CAPACITOR--START 340--408UF 047608
12 STRAP--CAPACITOR 7--11/32 037890
13 SCREW--8--32X5/16 SLTD 008399
