Taylor 340 Service Manual

49
+ Available Separately
Models 340/341/342 Parts List
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
342
QTY.
341
QTY.
340
QTY.
PART
NUMBER
BRUSH-DRAW VALVE 1”ODX2”X17”L 013073 1 1 1 000 BRUSH-MIX PUMP BODY-3”X7”WHITE 023316 1 1 1 000 BRUSH-REAR BRG 1IN.DX2IN.LGX14 013071 1 1 1 000 CASTER-SWV 5/8 STEM 4IN W 018794 4 4 103 COMPRESSOR - RS80C1E-CAV - COPELAND 051958- 1 1 2 512 340-J9026004/UP - (230 V Only),
341-J9012199/UP, 342-J8071822/UP
134, 137,
& 140
+CAPACITOR-RUN 20UF/440V 012906 1 1 2 103 208-230/60/1 +CAPACITOR-START 189-227UF/330V 033044-1 1 1 2 103 208-230/60/1 +RELAY-COMPRESSOR-START 051957-27 1 1 2 103 208-230/60/1
COMPRESSOR L61B562BBCB - BRISTOL 048727- 1 1 2 512 340 - J5113655-J9026004 (230V Only),
341-J5113655-J9012198, 342-J5092092-J8071821
+CAPACITOR-RUN- 20UF/370V 023606 1 1 2 103 208-230/60/1 +CAPACITOR-START-161-193UF/250V 031790 1 1 2 103 208-230/60/1 +RELAY-START-COMPRESSOR 048765 1 1 2 103 208-230/60/1 +CAPACITOR-RUN- 20UF/370V 023606 1 1 2 103 115/60/1 +CAPACITOR-START-189-227UF/330V 033044-1 1 1 2 103 115/60/1 +RELAY-START-COMPRESSOR 049656 1 1 2 103 115/60/1
COMPRESSOR AJ7455Z *-115V-TECUMSEH 050301-12 1 512 115/60/1 J6053972/UP
+CAPACITOR-RUN- 15UF/370V 027087 1 103 115/60/1 J6053972/UP +CAPACITOR-START-340-408UF/165V 047608 1 103 115/60/1 J6053972/UP +RELAY-START-COMPRESSOR 047609 1 103 115/60/1 J6053972/UP
* Also includes serial numbers J6041406 thru J6041448, and J6041459 thru J6041472. CONDENSER-AC-15LX14HX2.59T-3RW 046558 1 103 CONDENSER-AC-12LX18HX2.6T 048233 1 2 103 CONTROL-MIX LEVEL 031799- 1 1 2 103 COVER A.-HOPPER-STD X38458-SER 1 1 2 103
+GASKET-HOPPER COVER-20 QT-SGL 038375 1 1 2 000 KNOB-MIX COVER 025429 1 1 2 103
DECAL-CLEAN INST.-HOPPER 019029 1 1 1 000 DECAL-DEC-TAYLOR 021872 1 1 1 000 340 & 341 - PRIOR TO J7010000
