Parts List Models 340/341/342
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
342
QTY.
341
QTY.
340
QTY.
PART
NUMBER
WATER COOLED
ACCUMULATOR-COPPER 2”DIA 10”LG 047062 1 1 2 103
BLOWER-100 CFM 012796- 1 1 103
BRACKET-MOUNTING-WATER VALVE 038777 1 1 103
CONDENSER-WC-COAX 048287 1 2 103
CONDENSER-WC-SPIRAL 11-1/2 OD 049309 1 103
GUARD-BLOWER 022505 2 103
HOSE-RUBBER 1/2 ID X 7/8 OD R50200 4ft 4ft 8ft 000
MOTOR-FAN 9 WATT 1550RPM-CW 012768- 1 103
+FAN-5 BLADE 7 ” PUSH 30DEG CW 016289 1 103
OUTLET A.-TEE X25900 1 103
PANEL A.-SIDE LOWER X24397 2 103
SWITCH-PRESSURE 350 PSI-SOLDER 048231 1 1 2 103
TEE-3/8” PIPE WATER VALVE 032953 1 103
VALVE-WATER 3/8 REG/HEAD PRESS 046686 1 1 2 103
50Hz
BELT-V-4L470 007994 1 000
BELT-V-4L410 007530 1 000
BELT-V-4L440 009387 2 000
BLOCK-TERMINAL-7 POLE GREEN 024156 1 2 103
COMPRESSOR RS80C1E-CAZ (COPELAND) 051958- 1 1 2 512 340-J9073064/UP (208-230/50/1)
341-J9012199/UP, 342-J8071822/UP
+CAPACITOR-RUN - 20UF/370V 023606 1 1 2 103 208-230/50/1
+CAPACITOR-START-64-77UF/250 051960 1 1 2 103 208-230/50/1
+RELAY-START-COMPRESSOR 051957-40 1 1 2 103 208-230/50/1
COMPRESSOR L61B562BBKB (BRISTOL) 048727- 1 1 2 512
+CAPACITOR-RUN- 15UF/370V 027087 1 1 2 103 208-230/50/1
+CAPACITOR-START-161-193UF/250V 031790 1 1 2 103 208-230/50/1
+RELAY-START-COMPRESSOR 048766 1 1 2 103 208-230/50/1
DIAGRAM-WIRING *340-341-342* 049359-40 1 1 2 000
MOTOR-FAN 100W 220-240V 50HZ 047178-34 1 1 103 208-230/50/1
PULLEY-AK27-1/2 016190 1 1 2 103 BEATER MOTOR
