4
Introduction
Models 340/341/342
Model 340 Specifications
Freezing Cylinder
One, 7 quart (6.6 liter) capacity.
Mix Hopper
One, 20 quart (18.9 liter) capacity.
Beater Mo tor
One, .25 hp. motor.
Refrigeratio n Unit
One, approximately 6,000 btu/hr compressor.
Refrigerant 404A.
Electrical
Electrical
One dedicated connection.
Maximum
Fuse Size
Minimum
Circ uit Ampacity
115/60/1 Air 30 20
115/60/1 Water 25 18
208--230/60/1 Air 20 14
208--230/60/1 Water 20 14
220--240/50/1 Air 15 11
For exact electrical information, always refer to the
data label of the unit.
Air Cooled
Clearance: 6” (152 mm) around both sides. It is
recommended to install a skirt to one side of the unit
and place the back of the unit against a wall.
Water Cooled
W ater inlet and drain connections under side of base
3/8” FPT.
Dimensions
Width: 18--7/16” (468 mm)
Depth: 31” (787 mm)
Height: 36--3/8” (924 mm)
Counter Clearance: 4--1/4” (108 mm) mounted on
standard legs.
Approximate Weights
Net: 253 lbs. (114.8 kgs.)
Crated: 321 lbs. (145.6 kgs), 20 cu. ft. (.56 cu. m.)
Specifications are subject to change without notice.
This unit is designed and constructed to meet stringent
safety and sanitation requirements for NSF, UL, and
CSA.
