Mix Level Control Board
Taylor 12 Model 490
Short
Function
1 & 3
Out Continuousunction
2 & 4
Low Continuousunction
3 & 5
Out Blinkingnction
4 & 6
Low Blinkingunction
Mix Low/Mix Out Light Programming Jumpers
