Taylor 702 Service Manual


0RGHOV 
3DUWV
0RGHO  ([SORGHG 9LHZ
,7(0 '(6&5,37,21 3$57 12
1 SHELL A.-INSULATED X49770
1a BEARING-REAR SHELL 031324
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 SHIELD-MIX-GEAR REDUCER 013356
3 GEAR A.*REDUCER 4.21:1 012235
4 PULLEY-2AK74-5/8 027822
5 BELT-AX38 023873
6 PULLEY-2AK28-7/8 010294
7 MOTOR-2.0 HP 017650-
8 CLAMP-MOUNTING 012257
9 BUSHING-MOUNTING 012258
10 HINGE A.-MOTOR X25703
11 GROMMET-SHOCK ABSORB. 016212
12 SPRING-COMP .970X.115X2.0 025707
13 CAP-RUBBER MOUNT 011844
14 DRYER-FILTER-HP62-3/8 X 1/4 048901
15 BLOWER A. SEE PG. 45
16 SHROUD-TOP PANEL 013820
17 SHROUD-RIGHT 013822
18 SHROUD-LEFT 013821
19 SWITCH-PRESSURE 440 PSI 048230
20 VALVE-ACCESS 1/4FL X 3/8 044455
21 RECEIVER A.-REFRIGERANT X48348
22 CONDENSER-AC-12LX18H 048233
23 CONDENSER-AC 7X6X1.25 027155
24 DRYER-CAP TUBE 047699
25 SHROUD-DANFOSS 027386
26 MOTOR-FAN 105CFM 3000 027309
27 COMPRESSOR TL3G-R134A 047701-
28 KIT-MTNG. COMPRESSOR 047704
29 VALVE-ACCESS-1/4 FLX1/4 044404
30 VALVE-EPR 1/4S 022665
,7(0 '(6&5,37,21 3$57 12
31 VALVE-ACCESS 1/4FL X 1/4 044404
32 COMPRESSOR
AHA2490ZXD-AH556E
047519-
33 VALVE-ACCESS-1/4 MFL X 1/4 047016
34 ADAPTOR A.-CASTER X18915
35 CASTER-SWV 5/8 STEM 018794
36 GROMMET-COMPRESSOR MT 039923
37 CONTROL A. SEE PG. 39
38 COVER-CONTROL BOX 023016
39 SWITCH-TOGGLE-ON/NONE 024295
40 PANEL A.-FRONT X14238-SP
41 BOLT-CARRIAGE 1/4-20 X 3/4 012347
42 SWITCH A.-DRAW X28891-SER
43 CONTROL-TEMPERATURE 028914
44 BRACKET-TEMP CONTROL 021664
45 PLATE-DEC-SNGL-SWITCH 022604
46 RELAY-DPDT-20A-230V 026581-
47 TRANSFORMER-240V PR 030132-
48 CONTROL-THERMISTOR X46015-SER
49 TIMER-CYCLE 037188-
50 BRACKET-ROCKER SWITCH 020820
51 SWITCH-ROCKER-ON-OFF 014237
52 LIGHT-ORANGE-ROUND 017450
53 STUD-NOSE CONE 022822
54 GUIDE A.-DRIP PAN X28698
55 BOX A.-CAP&RELAY SEE PG. 42
56 PROBE A.-MIX X30922
57 DISC-PROBE *SQ HOLE* 030965
58 SPACER-PROBE *SQ HOLE* 030966
59 VALVE-EXP-AUTO-1/4S X1/4 046365
60 SLEEVE-MTG COMPRESSOR 039924
61 LIGHT-RED-RECT-250V-MIX
LOW
023056-
62* PROBE A.-THERMISTOR X31602
*NOT SHOWN
