0RGHOV
3DUWV
0RGHO ([SORGHG 9LHZ
,7(0 '(6&5,37,21 3$57 12
1 SHELL A.-INSULATED X49770
1a BEARING-REAR SHELL 031324
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 PROBE A.-MIX X30922
3 DISC-PROBE *SQ HOLE* 030965
4 SPACER-PROBE *SQ HOLE* 030966
5 SHIELD-MIX-GEAR REDUCER 013356
6 GEAR A.*REDUCER 4.21:1 012235
7 PULLEY-2AK64-5/8 BORE 039695
8 BELT-AX36 022849
9 PULLEY-2AK22-7/8 019987
10 MOTOR-2.0 HP 017650-
11 GROMMET 016212
12 SPRING-COMP. .970X.115X1.5 032967
13 CAP-RUBBER MOUNT 011844
14 HINGE A.-MOTOR X25703
15 GUIDE A.-DRIP PAN X28698
16 SHROUD-TOP 031222
17 SHROUD-CONDENSER REAR 051184
18 DRYER-FILTER-HP62-3/8 048901
19 CONDENSER-AC-12LX18HX 050682
20 VALVE-EXP-AUTO-1/4S X1/4 046365
21 BLOWER A. SEE PG. 45
22 SHROUD-CONDENSER*FRNT 051183
23 VALVE-ACCESS 1/4FL X 3/8 044455
24 SWITCH-PRESSURE 440 PSI 048230
25 VALVE-ACCESS-1/4 MFLX1/4 S 047016
26 COMPRESSOR L63A113BBCA 048259-
27 GROMMET-COMPRESSOR
MT.
037428
,7(0 '(6&5,37,21 3$57 12
28 ADAPTOR A.-CASTER X18915
29 CASTER-SWV 5/8 STEM 018794
30 DRYER-CAP TUBE 047699
31 KIT-MNTG-COMPRESSOR 047704
32 COMPRESSOR TL3G-R134A 047701-
33 VALVE-EPR 1/4S 022665
34 VALVE-ACCESS 1/4FL X 1/4 044404
35 BOX A.-CAP&RELAY SEE PG. 43
36 CONTROL ASSEMBLY SEE PG. 40
37 COVER-CONTROL BOX 024440
38 CONTROL-THERMISTOR X46015-SER
39 BOLT-CARRIAGE 1/4-20 012347
40 PANEL A.-FRONT X51264
41 SWITCH A.-DRAW X51242
42 PLATE-DEC 022602
43 RELAY-DPDT-20A-230V 026581-
44 TRANS.-240V PR1/24V SEC 10 030132-
45 BRACKET-ROCKER SWITCH 020820
46 SWITCH-ROCKER-ON-OFF-ON 014237
47 LIGHT-ORANGE-ROUND 017450
48 SWITCH-TOGGLE-ON-NONE 024295
49 CONTROL-TEMPERATURE 028914
50 BRACKET-TEMP CONTROL 021664
51 TIMER-CYCLE 037188-
52 LIGHT-RED-RECT-250V 023056-
53 MOTOR-FAN 105CFM 3000 027309-
54 SHROUD-DANFOSS 027386
55 CONDENSER-AC-7X6X1.25 027155
56 STUD-NOSE CONE 022822
57 SLEEVE-COMP-MOUNTING 037429
58 PROBE A.-THERMISTOR X31602
