0RGHOV
3DUWV
0RGHO 3DQHO 3DUWV ,GHQWLILFDWLRQ
,7(0 '(6&5,37,21 3$57 12
1 PANEL-UPPER·SIDE·LEFT 028700
2 BUSHING-PANEL 013289
3 COVER A.-HOPPER INSUL. X39291-SER
3a KNOB-MIX COVER 025429
4 TRIM-REAR·CORNER·LEFT 013761
5 HOOD 023263
6 PANEL-REAR 017563
7 LOUVER-SIDEL&R 017471
8 TRIM-REAR·CORNER·RIGHT 013663
9 PANEL-UPPER·SIDE-RIGHT 028701
10 PAN-DRIP·11-5/8·LONG 027503
11 PANEL·A.-SIDE RIGHT X44855-SER
,7(0 '(6&5,37,21 3$57 12
12 SCREW-1/4-20 X 3/8 RHM-SS 011694
13 )$67(1(5&/,3 8
14 ANGLE-TRIM·CORNER-R 013828
15 PANEL-SERVICE 046584
16 TRAY-DRIP·22-7/8L·X·5-1/8W 014533
17 SHIELD-SPLASH 037041
18 PANEL·A.-SIDE LEFT X44853-SER
19 PANEL A.-FRONT X51264
20 DECAL-DEC-TAYLOR 021872
21 PLATE-DEC-TWIN 022602
22 TUBE-FEED-SS-3/16 HOLE 028967-3
23 ANGLE-TRIM-CORNER LEFT 013829
