Taylor 702 - Model 741 Wiring Diagram


0RGHOV 
3DUWV
&RQWURO $ 0RGHO   ; 
,7(0 '(6&5,37,21 3$57 12
1 CONTROL-MIX LEVEL 031799-27
2 SCREW-8X1/4 SL HEX HD 009894
3 STARTER-1 PH 9 TO 15 AMP 041950-27M
4 RELAY-3 POLE-20A-208/240 012725-33
5 BLOCK-TERMINAL 2P-L1,L2 039422
6 SCREW-8 X 1-1/4 RD HD TYP B 039420
,7(0 '(6&5,37,21 3$57 12
7 LABEL-GROUNDING SYMBOL 017669
8 LABEL-COPPER COND ONLY 025948
9 LUG-GROUNDING 260 020928
10 SCREW-10-32X1/2 MF HEX 020982
11 NUT-10-32 MF LOCK 020983
