Taylor 702 Service Manual

 $YDLODEOH 6HSDUDWHO\

3DUWV /LVW 0RGHOV 
'(6&5,37,21 3$576
83'$7(
5(0$5.6:$55
&/$66

47<

47<

47<
3$57
180%(5
BEARING-FRONT 013116 2 000
CAP-DESIGN-1.188”ID-6 POINT 013139-6 2 000
GASKET-DOOR 5.177ID X 5.938OD 016672 2 000
O-RING-.643 OD X .077W 018572 4 000 FEED TUBE
O-RING-1-1/16 OD X.139W 020571 4 000 DRAW VALVE
SEAL-DRIVE SHAFT 032560 2 000 DRIVE SHAFT
TOOL-0-RING REMOVAL 048260-WHT 1 000
KNOB-DRAW VALVE 013635 1 1 2 103
+NUT-LOCK KNOB 013649 1 1 2 103
LABEL-DO NOT REMOVE GUARD 023844 1 000
LABEL-DOOR CAUTION 032749 1 1 1 000
LABEL-LEFT UNIT-RIGHT UNIT 023034 1 000 STIR TIMER
LABEL-MIX COOLING ADJ-INTL SYM 020217 1 1 1 000
LABEL-SWITCH-POWER OFF/STANDBY 052017-SYM 1 1 2 000 J8050000/UP (ON POSITION AT RIGHT) 129
LABEL-WARM-COLD INT’LSYMBOL 013749 1 1 2 000
LABEL-WARN-COVER 051433 5 4 6 000
LABEL-WIRING THREE PHASE 036880-3 1 000
LEG-4” SS-W/ORING 013458 4 103
LIGHT-INDICATOR-ORANGE-ROUND 017450 1 1 2 103
LIGHT-AMBER-RECT. 250VAC 047141-27 1 103 J9010000/UP 137
LIGHT-INDICATOR-RED-RECT. 023056- 1 1 2 103 MIX LOW
LOUVER-SIDE 013631 2 103
LOUVER-SIDE 017471 2 103
LUBRICANT-TAYLOR 4 OZ. 047518 1 1 1 000
MAN-OPER 700 DUAL MASTER 028759-M 1 1 1 000
MOTOR-1.0 HP 013102- 1 212
MOTOR-2.0 HP 017650- 1 2 212
MOTOR-FAN 027309-27 1 1 1 103 SHR 208/230VOLT
BLADE-FAN BLACK PRESS 050893 1   103
MOTOR-FAN 50 WATT 029770-27 1 103 208/230VOLT
+FAN-5 BLADE 12” PUSH 22DEG CCW 049009 1 103
NUT-STUD *GENERAL USAGE* 021508 4 4 4 103 HANDSCREWS
PAIL-6 QT. 023348 1 000
PAIL-MIX 10 QT. 013163 1 1 000
PAN-DRIP 13-1/4 LONG 039027 1 103
