Taylor 702 User Manual

+ Available Separately
SHR (Separate Hopper Refrigeration)
30
Parts List Models 702/741/772
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
772
QTY.
741
QTY.
702
QTY.
PART
NUMBER
+KNOB--ALUMINUM 027422 1 1 2 103
COVER A. --HOPPER--STD X38458 --SER 1 1 103 INCLUDES KNOB
KNOB --MIX COVER 025429 1 1 103
+GASKET --HOPPER COVER--20 QT --SGL 038375 1 1 000
COVER--HOPPER *GRAY* 053809 2 103 DECAL --DEC--TAYLOR 021872 1 1 1 000 LABEL --SWITCH--OFF/STANDBY--SYMBO 052017--SYM 1 1 2 000 REPLACES 048493 DECAL --TROUBLESHOOTING 038374 1 1 1 000 DEFLECTOR--BLOWER EXHAUST 048345 1 103 DEFLECTOR--BLOWER EXHAUST 046586 1 103 DIAGRAM--WIRING *702* 063149--27 1 000 DIAGRAM--WIRING *741* 063287--27 1 000 DIAGRAM--WIRING 051069-- 1 000 DOOR A. --1 SPOUT--4 QT X30269 --SER 1 103
+DECAL --LIFT PLATE FRONT 015200 1 000 +VALVE A.--DRAW X13624--SP 1 103
+O--RING--1 --1/16 OD X.139W 020571 2 000
DOOR A. --1 SPOUT--7 QT X30272 --SER 1 2 103
+DECAL --LIFT PLATE FRONT 015200 1 2 000 +VALVE A.--DRAW X13624--SP 1 2 103
+O--RING--1 --1/16 OD X.139W 020571 2 4 000
DRYER--CAP. TUBE--HP62/R134A 047699 1 1 1 000 SHR DRYER --FILTER--HP62--3/8 X 1/4S 048901 1 1 2 000 REPLACES 047521 DVD--OPS TRAIN VIDEO*700 SERIES 043568--DVD 1 1 1 000 FASTENER--CLIP 045865 4 8 000 PANELS FILTER --CORCOM 2VR1 032567 1 1 1 103 GASKET --DOOR 5.177ID X 5.938OD 016672 1 1 2 000 GEAR A.*REDUCER 012235--SER 1 1 2 212 GUARD--BELT 013576 1 103 GUARD--BELT 023843 1 103 GUIDE A. --DRIP PAN*702* X50814 1 103 GUIDEA.--DRIPPAN X28698 1 2 103 HOOD 021222 1 103
