Taylor 702 User Manual

31
+ Available Separately
SHR (Separate Hopper Refrigeration)
Models 702/741/772 Parts List
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
772
QTY.
741
QTY.
702
QTY.
PART
NUMBER
HOOD 023285 1 103 HOOD 023263 1 103 KIT A.--MOTOR--FAN X62253--27 1 1 1 103 KIT A.--TUNE UP*710--715--731--741 X33926 1 1 000
BEARING--FRONT 013116 1 1 000 CAP--DESIGN--1.188”ID--6 POINT 013139 --6 1 1 000 GASKET --DOOR 5.177ID X 5.938OD 016672 1 1 000 O--RING--.643 OD X .077W 018572 2 2 000 FEED TUBE O--RING --1--1/16 OD X.139W 020571 2 2 000 DRAW VALVE SEAL --DRIVE SHAFT 032560 1 1 000 DRIVE SHAFT TOOL-- 0--RING REMOVAL 048260--WHT 1 1 000
KIT A.--TUNE UP*733--777* X33928 1 000
BEARING--FRONT 013116 2 000 CAP--DESIGN--1.188”ID--6 POINT 013139 --6 2 000 GASKET --DOOR 5.177ID X 5.938OD 016672 2 000 O--RING--.643 OD X .077W 018572 4 000 FEED TUBE O--RING --1--1/16 OD X.139W 020571 4 000 DRAW VALVE SEAL --DRIVE SHAFT 032560 2 000 DRIVE SHAFT TOOL-- 0--RING REMOVAL 048260--WHT 1 000
KNOB--DRAW VALVE 013635 1 1 2 103
+NUT --LOCK KNOB 013649 1 1 2 103
LABEL --DO NOT REMOVE GUARD 023844 1 000 LABEL --DOOR CAUTION 032749 1 1 1 000 LABEL --LEFT UNIT--RIGHT UNIT 023034 1 000 STIR TIMER LABEL --SWITCH--POWER OFF/STANDBY (NEW) 052017--SYM 1 1 2 000 J8050000/UP (ON POSITION
AT RIGHT)
129
LABEL --WARM--COLD INT’L SYMBOL 013749 1 1 2 000 LABEL --WARN --COVER 051433 5 4 6 000 LEG--4” SS--W/ORING 013458 4 103 LIGHT--INDICATOR--ORANGE--ROUND 017450 1 1 2 103 LIGHT--AMBER --RECT. 250VAC 047141--27 1 103 J9010000/UP 137 LIGHT--INDICATOR--RED--RECT. 023056--27 1 1 2 103 MIX LOW LOUVER--SIDE 051192 2 103 REPLACES 013631
