Models 702/741/772 Parts List
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
772
QTY.
741
QTY.
702
QTY.
PART
NUMBER
PLATE--DEC--SINGLE --ROCKER SWITCH 022604 1 1 103 PLATE--DEC--TWIN--ROCKER SWITCH 022602 1 103 PLUG--DRIP TRAY HOLE 029595 1 103 PROBE A. --MIX *SQUARE* X30922 1 1 2 103
+DISC--PROBE *SQ HOLE* 030965 1 1 2 103 +SPACER--PROBE *SQ HOLE* 030966 1 1 2 103
PROBE A. --THERMISTOR X31602 1 1 2 103 PULLEY--2AK22--7/8 019987 2 103 BEATER MOTOR PULLEY--2AK27 X .625--.6265 011545 1 103 BEATER MOTOR PULLEY--2AK28--7/8 010294 1 103 BEATER MOTOR PULLEY--2AK64 --5/8 BORE 039695 2 103 GEAR PULLEY--2AK74--5/8 027822 1 1 103 GEAR RELAY --3 POLE 012725--33 1 1 2 103 208/230V RELAY --DPDT--20 A --230 V 026581--27 1 1 3 103 STIR CYCLE TIMER 208/230V SANITIZER KAY --5 125 PACKETS 041082 1 1 1 000 SHAFT --BEATER 033498 1 1 2 103
+SEAL --DRIVE SHAFT 032560 1 1 2 000
SHELL A. --INSULATED*702*12 INCH X50815--SER 1 512
+STUD--NOSE CONE 022822 4 103
SHELL A. --INSULATED *19 INCH* X49770--SER 1 2 512
+STUD--NOSE CONE 022822 4 8 103
SHIELD--MIX --GEAR REDUCER 3--3/8” 013356 1 1 2 103 SHIELD--SPLASH 037041 1 103 SHIELD--SPLASH 15”L X 5 --13/32”W 022763 1 1 103 SKIRT--AIR FLOW 049069 1 103 STARTER--BEATER 041950--27K 1 2 103 208 --230V 60HZ 1 PH
OVERLOAD--THERMAL 047150--27K 1 2 103 76
STARTER--3 PHASE--3 TO 5 AMP 041950--33J 1 208--230V 60HZ 3 PH
OVERLOAD--THERMAL 047150--33J 1 2 103 76
STARTER--1 PHASE--9 TO 15 AMP 041950 --27M 1 208 --230V 60HZ 1PH
OVERLOAD--THERMAL 047150--27M 1 2 103 76
STARTER--3 PHASE --4.5 TO 7.5 AMP 041950--33K 1 103 208--230V 60HZ 3PH
OVERLOAD--THERMAL 047150--33K 1 103
