Taylor 702 User Manual

+ Available Separately
SHR (Separate Hopper Refrigeration)
34
Parts List Models 702/741/772
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
772
QTY.
741
QTY.
702
QTY.
PART
NUMBER
SWITCH A. --DRAW *632--710--31--41-- X51242--SER 1 2 103
ARM A.--DRAW VALVE X28874 1 2 103 BRACKET --DOOR SWITCH 028875 1 2 103 E--RING 3/16 .335 O.D. 049178 1 2 000 PIN--PIVOT 015478 1 2 103 PLATE --DRAW VALVE LIMITER *702* 051241 1 2 103 SPRING--RETURN 015342 1 2 103 SWITCH--LEVER --SPDT--10A--125--250V 028889 2 4 103
SWITCH A. --DRAW *632--710--31--41-- X28891--SER 1 103
ARM A.--DRAW VALVE X28874 1 103 BRACKET --DOOR SWITCH 028875 1 103 E--RING 3/16 .335 O.D. 049178 1 000 PIN--PIVOT 015478 1 103 SPRING--RETURN 015342 1 103 SWITCH--LEVER --SPDT--10A--125--250V 028889 2 103
SWITCH--PRESSURE 405 PSI --SOLDER 052663 1 103 J9010000/UP -- COPELAND 137 SWITCH--PRESSURE 440 PSI --SOLDER 048230 1 1 2 103 702--PRIOR TO J9010000 137 SWITCH--ROCKER--DPDT ON--OFF--ON 014237 1 1 2 103
+BRACKET --ROCKER SWITCH 020820 1 1 2 103 +CARD--WASH --OFF--AUTO 014091 1 1 2 000
SWITCH--TOGGLE--DPDT*ON --NONE --ON 024295 1 1 2 103 SHR/CTR TIMER--CYCLE 5SEC ON/120SEC OFF 037188 --27 1 1 4 103 TRANS.--240V PR1/24V SEC 10 VA 030132 --27 1 1 2 103 TRAY-- DRIP 14-- 7/8L X 5-- 1/8 SGL 013690 1 1 103 TRAY-- DRIP 22-- 7/8L X 5-- 1/8W 014533 1 103 TRIM--CORNER *390*LEFT 047002 1 103 TRIM--CORNER *390*RIGHT 047003 1 103 TRIM--FRONT *340*DDO* 050913 1 103 REPLACES 047001 TRIM--REAR CORNER 013620 2 103 TRIM--REAR CORNER LEFT 013761 1 103 LEFT TRIM--REAR CORNER RIGHT 013663 1 103 RIGHT TUBE--FEED--SS--3/16 028967--3 1 2 103 TUBE--FEED--SS--5/32 HOLE 028967--2 1 103

Taylor 702 Specifications

General

Brand	Taylor
Model	702
Category	Freezer
Language	English
